Continuous Beam Calculator

ByPushplata Rajput

What is a Continuous Beam Calculator?

A continuous beam calculator is a tool used in structural engineering to analyze and design continuous beams.

Continuous beams are structural elements that extend over more than two supports, commonly used in building construction.

Why use a Continuous Beam Calculator?

  1. Structural Analysis: Helps engineers analyze continuous beams for reactions, shear forces, and bending moments.
  2. Design Optimization: Assists in optimizing beam dimensions for cost-effectiveness and structural efficiency.
  3. Safety Assurance: Ensures that the beam design meets safety and structural requirements.
  4. Code Compliance: Helps comply with local building codes and standards.

Continuous Beam Calculator






How to use a Continuous Beam Calculator:

  1. Enter the span length of the continuous beam.
  2. Select the type of support at points A and B (fixed or pinned).
  3. Choose the type of load (point load or uniform load).
  4. Enter the magnitude of the load in kips.
  5. Click the "Calculate" button.
  6. The calculator estimates reactions, shear forces, and bending moments at supports and along the length of the continuous beam.

Example of Calculator:

Let's say you have a continuous beam with the following specifications:

  1. Span Length = 20 feet
  2. Support A Type = Fixed
  3. Support B Type = Pinned
  4. Load Type = Point Load
  5. Load Value = 10 kips

Reactions: A = 5.00 kips, B = 5.00 kips
Shear Forces: A = 10.00 kips, B = 10.00 kips
Bending Moments: A = 100.00 kip-ft, B = 100.00 kip-ft

Note
