What is a Steel Tubing Span Calculator?

A steel tubing span calculator is a tool used to determine the maximum span or distance that a specific type and size of steel tubing can safely bridge or support a load.

It considers the properties of the tubing, such as type, outer diameter, wall thickness, material, and the applied load.

Why Use a Steel Tubing Span Calculator?

Using a steel tubing span calculator is crucial in structural engineering and construction to ensure that steel tubing is appropriately sized for a given application.

It helps in preventing structural failure and ensures the safety and stability of structures.



Steel Tubing Span Calculator

A steel tubing span calculator is a tool used to determine the maximum span or distance that a specific type and size of steel tubing can safely bridge or support a load. It requires input values for the properties of the steel tubing and the load conditions, providing an estimate of the maximum allowable span.






Result: The maximum allowable span for the steel tubing is approximately ? inches.

How to Use a Steel Tubing Span Calculator:

  1. Select the type of steel tubing (e.g., square or round).
  2. Input the outer diameter of the tubing in inches.
  3. Input the wall thickness of the tubing in inches.
  4. Input the material of the tubing.
  5. Input the applied load on the tubing in pounds.
  6. Click the "Calculate" button to perform the calculation.
  7. The calculator provides the estimated maximum allowable span for the steel tubing in inches.

Example Calculation:

Suppose you have square tubing with an outer diameter of 4 inches, a wall thickness of 0.25 inches, a material factor of 1.5, and an applied load of 500 pounds.

Using the calculator, you would find that the estimated maximum allowable span is approximately 1.13 inches.

Adjust the inputs based on your specific tubing dimensions, material, and load conditions.

Note: The example formula is simplified for demonstration purposes; actual calculations may involve complex engineering principles and standards.
